SOBOL NN VAN 3 SEATS
TEST DRIVE
DYNAMIC URBAN PERFORMANCE
Featuring compact dimensions, the Sobol NN offers the ultimate solution for cargo logistics in crowded urban environments.
- EXTERIOR
- INTERIOR
- CHASSIS
- SPECIFICATIONS
EXTERIOR
Sobol NN - Flexible & Modern mid-size van
- This mid-size cargo van stands out with a modern, dynamic silhouette, aligned with contemporary urban design trends. Its compact dimensions allow for agile maneuverability in congested city areas, while the rear cargo space remains spacious, effectively meeting diverse transport needs.
- It serves as the ideal choice for small transport businesses, logistics providers, and last-mile delivery services.
INTERIOR
Ergonomic interior - Optimized workspace
- The driver’s cabin is fully equipped and logically arranged, ensuring easy operation and comfort throughout the journey. The airy cabin integrates air conditioning, an entertainment system, power windows, and convenient storage compartments.
- At the rear, the cargo compartment features a high volume and a flat floor using robust, easy-to-clean materials, ensuring high durability suitable for continuous cargo transport operations in both urban and inter-city settings.
CHASSIS
SUPERIOR PERFORMANCE AND SAFETY
- The vehicle structure consists of 80% high-grade steel. The entire body frame utilizes high-alloy steel designed in a closed-section structure to enhance rigidity, stability, and safety. The chassis features a reinforced overlapping design that delivers optimal impact energy absorption, maximizing safety.
| PARAMETERS | UNIT | DETAIL |
|---|---|---|
| DIMENSIONS | ||
| Exterior dimensions (LxWxH) | mm | 5110 х 2068 х 2430 |
| Cargo Dimensions (LxWxH) | mm | 2600 x 1840 x 1640 (~ 7.8 m3) |
| Track – Front/Rear | mm | 1750 / 1750 |
| Wheelbase | mm | 3005 |
| Ground clearance | mm | 160 |
| WEIGHT | ||
| Curb weight | kg | 2360 |
| Payload | kg | 945 |
| Gross weight | kg | 3500 |
| Capacity | Seats | 03 |
| ENGINE | ||
| Engine code | Cummins ISF2.8s5161P, Euro 5 | |
| Engine type | Diesel, 4-stroke, 4 in-line cylinders, turbocharged, intercooled, electronically controlled fuel injection | |
| Displacement | cc | 2776 |
| Max power | Ps/rpm | 150 / 3400 |
| Max torque | N.m/rpm | 320 / 1400 - 2700 |
| TRANSMISSION | ||
| Clutch | Single plate, dry friction, hydraulically operated | |
| Transmission | Manual, 5 forward gears, 1 reverse gear | |
| Gear ratio | ih1=3,786; ih2=2,188; ih3=1,304; ih4=1,000; ih5=0,794; iR=3,280 | |
| Main gear ratio | 4,3 | |
| STEERING SYSTEM & BRAKING SYSTEM | ||
| Steering system | Rack and Pinion, Hydraulic Power Assisted Steering | |
| Braking system | Vacuum Assisted Hydraulic Brakes, Disc Brakes, Equipped with ABS and EBD | |
| SUSPENSION SYSTEM | ||
| Front | Independent, Coil Spring, Hydraulic Shock Absorber, Stabilizer bar | |
| Rear | Dependent, Leaf Spring, Hydraulic Shock Absorber, Stabilizer bar | |
| Tires | Front/rear | 235/65R16C |
| CHARACTERISTIC | ||
| Gradeability | % | 26 |
| Minimum Turning Radius | m | 5,4 |
| Maximum Speed | km/h | 130 |
| Fuel Tank Capacity | liter | 80 |
| STANDARD EQUIPMENT | ||
| Entertainment system | 2 DIN android unit | |
| Rear-view mirrors | Electric adjustment and heated | |
| Cruise Control System | Standard | |
| Rear door | 02 leaves, opens to 180° | |
| Air conditioning | Standard | |
